Human Sense MOVE EYE
Direct/Indirect Flow
Dual Barrier Coating
Plasma Quad Plus
Anti-mold filter (Air filter)
Deodorizing Fiter
Silver-ionized Air Purifier Filter (Optional)
Computerized Dehumidification
Inverter Control
Heat Pump
Wide Airflow
Powerful Cool
ECONO Cool
I Save Mode
Night Mode
Noise-Reducing Design
Vertical Auto Swing (7 Modes )
Horizontal Auto Swing
24 Hour Pre-set On/Off
Electric Circuit Protection
Auto Restart^
Self Diagnosis
^Auto Restart function must be set by qualified engineers. Please contact our service centers if you need technical support.
．The product specifications are provided by the factory of Mitsubishi Electric.
．Before purchase and installation, the space and position needed for installation should be confirmed by qualified engineers.
．Designs and specifications are subject to change without prior notice.
Note:
- The Global Warming Potential (GWP) of environmentally friendly refrigerant R32 is 675, which is about 1/3 of that of R410A, and it is mildly flammable.
- During installation, inspection or maintenance, please follow the instructions in the installation and service manual of R32 refrigerant air conditioner products ( pay attention to the installation height and minimum room area requirements, etc.).
- Please find qualified personnel for installation, inspection or maintenance.
Model Indoor Unit MSZ-LN12VFR MSZ-LN12VFB MSZ-LN12VFV
Outdoor Unit MUZ-LN12VF MUZ-LN12VF MUZ-LN12VF
Color Indoor Unit Ruby Red Onyx Black Peral White
Cooling / Heating Capacity Rated kW 3.50/4.00 3.50/4.00 3.50/4.00
BTU/h 11,942/13,648 11,942/13,648 11,942/13,648
Min-Max kW 0.80-4.00/0.90-6.30 0.80-4.00/0.90-6.30 0.80-4.00/0.90-6.30
BTU/h 2,730-13,648/3,412-21,496 2,730-13,648/3,412-21,496 2,730-13,648/3,412-21,496
Power Consumption Rated kW 0.82 0.82 0.82
Min-Max 0.16-1.18/0.17-1.88 0.16-1.18/0.17-1.88 0.16-1.18/0.17-1.88
Operating Current A 3.8/3.8 3.8/3.8 3.8/3.8
Air Circulation m³/min. 13.0/13.9 13.0/13.9 13.0/13.9
C.O.P. 4.27/4.88 4.27/4.88 4.27/4.88
Dehumidifying Capacity I/h 0.5 0.5 0.5
Noise Level Indoor Unit (Si)/Lo-Hi dB(A) 19-43/19-45 19-43/19-45 19-43/19-45
Outdoor Unit 49/50 49/50 49/50
Dimension (H x W x D)
Indoor Unit mm 307 x 890 x 233 307 x 890 x 233 307 x 890 x 233
Outdoor Unit 550 x 800 x 285 550 x 800 x 285 550 x 800 x 285
Weight Indoor Unit kg 15.5 15.5 15.5
Outdoor Unit 34 34 34
Refrigerant Pipe Diameter Liquid / Gas mm φ6.35/φ9.52 φ6.35/φ9.52 φ6.35/φ9.52
Max. Piping Dimension Height Difference / Length m 12/20 12/20 12/20
Voltage V 220 220 220
Phase / Frequency Single / 50 Hz Single / 50 Hz Single / 50 Hz
Refrigerant R32 R32 R32
Energy Efficiency Grade 1 1 1
Optional Parts Silver-ionized Air Purifier Filter Silver-ionized Air Purifier Filter Silver-ionized Air Purifier Filter
Remarks
The product specifications are provided by factories of Mitsubishi Electric.
Before purchase and installation, the space and position needed for installation should be confirmed by qualified engineers.
Designs and specifications are subject to change without prior notice.
