Description
Available capacity: 6.5 or 10 gal.
2025 New Grade 1 Energy Efficiency Label
Ten-Year warranty for inner tank
5-Tier safety device
Heavy gauge stainless steel inner tank
Multi-point application
Central Type Water Heater – Storage (Wall-Mount)
Heavy gauge stainless steel inner tank
Multi-point application
5-Tier safety device
Automatic Thermostatic Control
Temperature can be adjusted according to user’s preference. When the upper limit is reached, electricity would be cut off automatically; once the water temperature drops below the
lower limit, power will be resumed.
Thermal Circuit Breaker
If the water temperature reaches 82°C, power would be cut off automatically to ensure safety.
Temperature Relief Valve
When the water temperature reaches 90°C, the temperature relief valve will open automatically to prevent the buildup of steam pressure caused by continuous heating in the inner tank.
Pressure Relief Valve
Under abnormal circumstances where the inner tank is subject to excessive pressure (more than 1,000kPa (10 bar)), the pressure relief valve will open automatically to discharge water.
Anti-back Syphon Device
Hot water is prevented from being syphoned back to the supply pipe during water shortage. This effectively prevents inner tank damages and dry-heating.
Specifications
Information
Sub ModelGPU-6.5HE-V | GPU-10HE-V
Capacity: Water Storage6.5 gal (25 L) | 10 gal (40 L)
Voltage220 V
Power3 kW
Colourwhite
Dimensions(6.5 gal) (H) 660 (W) 310 (D) 310 mm
(10 gal) (H) 720 (W) 360 (D) 360 mm
Packing Dimensions(6.5 gal) (H) 385 (W) 765 (D) 385 mm
(10 gal) (H) 440 (W) 805 (D) 425 mm
Net Weight(6.5 gal) 14.1 kg
(10 gal) 19.4 kg
gross weight inc. packaging(6.5 gal) 15.9 kg
(10 gal) 21.5 kg
Net Weight: Full Tank(6.5 gal) 39.3 kg
(10 gal) 59.5 kg
Power Supply1 Phase
Electric Current15A
Functions & Features
Working Pressure1 MPa
Testing Pressure1.2 MPa
Water ResistanceIPX4
Included AccessoriesWater & Energy Saving Aerated Shower Head
Others
Warranty Term1 Year
Warranty Term10 Years on Inner Tank *
Energy Efficiency ClassGrade 1 (2025)
Certification / StandardIEC 60335-1、IEC60335-2-21
